Monolayer Film Extrusion Machine

Monolayer Film Extrusion Machine

Inquiry Now
About Us
At NGCE, a subsidiary of REW, we take pride in being a leading manufacturer of monolayer extrusion plants for a wide range of materials, including LDPE, LLDPE, HDPE, EVA, PLA, PBAT, PP, Re-Process material, Biopolymers, and Compostable materials. With over 30 years of experience, we have established ourselves as a reliable and innovative partner in the blown film industry.

Our Products
Monolayer Extrusion Plants
Our state-of-the-art monolayer extrusion plants are designed to meet the diverse needs of our customers. Key features include:

Film Width: 100 mm - 800 mm
Film Thickness: 20 - 120 micron
Material Compatibility: LDPE, LLDPE, HDPE, EVA, PLA, PBAT, PP, Re-Process material, Biopolymers, Compostable materials
Structure: Strong and compact, made from a special grade steel alloy
Gearbox: Helical gearbox developed with robust R&D
Drives: European-class AC drives
Feed Section: Grooved feed section with Bimetallic alloy
Screw Design: Tested screw design with 30 years of service
Filter: Customized candle-type filter
Die: High output chrome plated die
Cooling Ring: High cooling ring
Rollers: Dynamically balanced rollers
Winder: Surface winder attached, synchronized nip & winder unit
Hoper: Magnetic SS-hoper
Safety: Cold start preventer
Model - 45 mm Standard
Total Power: 40 HP
Screw Size: 45 mm
Nip Roll: 900 mm
Layflat: 800 m
Output: 55 kg/Hr
Main Motor: 20 HP
Blower: 3 HP
Screw: Nitrided/bimetallic
Optional Features
Enhance your production capabilities with our optional features:

Rotating Die
Embossing Rollers
Bubble Break Sensor & ACS
Inline Printing
Corona Treatment Unit
Vacuum Loader, Hopper Dryer
Screen Changers: Lever/Hydraulic/Continuous
Station: Single/Double
Winder: Attached/Separate, as per requirement
Contact Us
NGCE is committed to providing cutting-edge blown film solutions to meet your specific requirements. Contact us today to discuss how our expertise and technology can elevate your production capabilities. Whatsapp: 8128381431
